Architecture

Overview

../_images/high-level-architecture.svg

As depicted in the above figure, the system features a 3-tier architecture approach, consisting of a frontend, backend, and data layer. Each component in these layers is containerized to ensure portability. The backend is handled via a centralized component running a FastAPI web server. Upon REST requests from the frontend, the Core either creates new containers, running specified the IDS, or propagates the request to an existing instance. In addition to the IDS itself, these IDS containers also feature a FastAPI server to allow RESTful communication with the Core. To aggregate the results and be able to inject them into Grafana, both a Prometheus and a Loki instance are required. When analyses and metrics are collected, the respective results are sent from the IDS container to the Core and then propagated to Prometheus for metrics and Loki for logs.

Database Schema

The database is predominantly used to create and store configurations related to the various IDS and ensembles. This includes a table for available IDS setups, currently running IDS containers, configured ensembles, and possible ensembling techniques. Additionally, the database stores a diverse set of configuration files for each IDS and rulesets for signature-based ones. Lastly, datasets uploaded via the GUI are stored as well. However, only the paths to the files are saved in the database, while the files themselves are stored on the Core in unique directories. This approach allows for arbitrary dataset sizes and faster database transactions, as the files do not need to be loaded in memory for each get request. The following ER model illustrates the database configuration.

../_images/ER-diagram.png

In addition to the entities described above, several helper tables exist. For instance, the docker_host _system table stores host information for local and remote Docker hosts. The intermediate table ensemble_ids associates running containers with ensembles. Further helper attributes exist in these tables to assist in managing requests and application state. However, these will be introduced in the following backend section, where their use is explained in greater detail.

Note

This part especially is subject to changes in the future and might be outdated. Make sure to double check information given here with the actual ORM implementations or DB scripts.

Common communication standard

As the architecture depiction above implies, different IDS send their results to the Core. This central component then handles the combination and evaluation. However, different IDS offer different alert formats. Therefore, it is necessary to convert each result set into a common standard to allow the Core to analyse them indifferently. To accomplish this, either the Core needs to convert each result or the IDS containers need to adjust their formats accordingly. The latter approach is chosen, as it better fulfills the requirements of expandability and maintainability. Modules for each IDS can be implemented and maintained separately from the Core logic, allowing updates to the IDS modules without changing the Core. The common standard must fulfill its own requirements. For one, it needs to be specific enough to allow an assignment of alerts to labels for static analyses. On the other hand, it must be generic enough so that every IDS can potentially fill out each field of the standard. As a compromise between specific information and broad applicability, the format depicted below is adpoted.

{
    "time": "2017-07-07T09:01:14.000000+0000",
    "source_ip": "192.168.10.3",
    "source_port": "88",
    "destination_ip": "192.168.10.25",
    "desitnation_port": "49177",
    "severity": "1",
    "type": "alert",
    "message": "SURICATA Kerberos 5 weak encryption parameters"
}

The format itself is self-explanatory. The information can be filled out by any IDS and allows for the correct assignment of alerted requests to labels. It should be noted, however, that the severity can differ between IDS implementations. This can lead to problems when trying to combine alerts from different solutions into one ensemble. Therefore, the severity needs to be scaled accordingly for each IDS:

\[ScaledSeverity = \frac{Outputted Severity}{Maximum IDS Severity}\]

Plugin System

For the Core to communicate with IDS instances, a REST server based on FastAPI is used. This server handles requests from the central component, processes them, and forwards them to the underlying IDS. To facilitate the implementation, and extendability, a common base is defined. This base includes the REST server and abstract classes and interfaces that need to be implemented with specialized logic for each IDS. By using this base, implementing the classes and interfaces, and finally building an image from it, a new IDS can be introduced to the Core

../_images/abstract_base_classes.drawio.svg

As shown, there are two primary abstract classes: the Parser class and the IDSBase class. Both require a system-specific implementation of the methods marked as abstract, to create a new plugin. The Alert class, on the other hand, is used by the Parser to convert the logs from one system into the common format described in common communication standard. The methods of these primary classes are invoked by the REST server when handling requests. Due to environment variables injected at runtime, the server can instantiate a Singleton of the appropriate class. This instance is then stored in the FastAPI state, ensuring that subsequent calls are handled by the same object. This approach facilitates state handling within the container, eliminating the need to persist each change in the database.

Communication Flows

Lifecycle Management

Before analyses can be run, the life cycle of an IDS container must be managed. As mentioned above, upon user request, the Core instantiates a Docker container and manages its state according to the user’s instructions. Simultaneously, the runtime metrics of the container are collected. These are the RAM consumption in MB, and the CPU utilization in percent. The below figure illustrates the flow of communication between the frontend, Core, IDS container, and Prometheus Pushgateway for setup and teardown actions. Please note that this illustration represents the sequence of actions at a high level of abstraction rather than at the functional level, as a detailed diagram would be too extensive.

../_images/sequence-diagram-lifecycle.png

Lifecycle management representation of the IDS management

As depicted, the Core handles input from the frontend using the Docker SDK to spin up or tear down the container. After a successful start, the Core checks whether the container is ready to receive requests by calling the health check endpoint. If a status code of 200 is returned, the Core injects the main configuration file and, if necessary, the ruleset into the container. Subsequently, the container status is updated and set to IDLE, allowing the user to receive visual feedback in the frontend indicating that the container is ready for requests. After this initial setup, BICEP ensures that a metric-service is running on the respective Docker host. This host-local service collects CPU and RAM metrics for the containers on that host and pushes each scrape directly to the Prometheus Pushgateway. These metrics are then used by Grafana to create a CPU and RAM dashboard, which is embedded in the frontend.

Single Container Analyses

Once the setup is complete, the container can be used to execute analyses. The sequence diagrams below demonstrate the flow of actions for static and network analyses between the Core and a single IDS instance. As depicted, in both cases, the Core sends a request to a dedicated endpoint of the IDS. The URL is composed of a combination of its Docker host and the port assigned to the IDS during setup. For a static analysis, the instance handles the request by saving the static pcap file to disk. After that, the IDS object executes the solution-specific OS-command in a background process. When this process is finished, the instance reports back to the Core by sending two requests: one to indicate that the analysis is complete so that its status can be reset to IDLE. The other is used to send the alerts generated by the IDS from the dataset to the Core. For the latter, the respective IDS parser object is used to convert the log entries of the system into the common standard described in common communication standard. \ For a network analysis, the first step is to ensure that a tap network interface is set up to mirror all incoming traffic from its Docker host on the main network interface to the tap interface. Since no dataset file needs to be exchanged, the OS command is executed directly afterward, listening to the aforementioned tap interface. This task is also executed in the background. Generated alerts are parsed and sent to the Core periodically by another background task. To keep track of this, the task is saved in the Singleton object in the FastAPI state by assigning it to the variable send_alerts_periodically_task. This allows the task to be canceled later. For a cancellation, another API call from the Core to the IDS instance can be made to invoke the stop_analysis method of the Singleton object. This methodresets the send_alerts_periodically_task variable, stops the task, removes the tap interface, and sends a request to the Core to update the IDS status to IDLE again.

../_images/sequence-diagram-static.png

Workflow representation of a static analysis

../_images/sequence-diagram-network.png

Workflow representation of a live network analysis

Ensembling

Creating an ensemble is a straightforward process, since it is only a logical connection between existing IDS containers. The only requirement is that the containers are already set up. A user can then combine as many containers as desired into an ensemble using the frontend. This action updates the database by adding entries to the ensemble_ids table. Analyses in an ensemble work similarly to those for a single system, as the Core endpoint for an ensemble uses the same class methods as for a standalone system. The backend loops over each container and executes the previously described methods for static or network analysis. The results are then handled differently, as explained in the following.

Static Analysis for Ensembles

In contrast to an analysis for a single system, the ensemble endpoint must handle multiple instances that send their results independently. Thus, when an ensemble initiates a static analysis, all entries in the ensemble_ids table for that ensemble are updated to the PROCESSING status. When an IDS result arrives, the endpoint pushes the alerts, and then updates the database entry, setting the status to IDLE. This allows the endpoint to check whether the container that sent the alerts is the last one running. If it is not the last, the endpoint continues to wait for the final container to send its results. Once the final container completes its task, all alerts are retrieved from Loki. To identify the alerts of the other containers of the ensemble, a round mechanism is introduced. Each round is identified by a UUID, which is initially set when starting an analysis for the ensemble. This UUID serves as a label for each log in a round (in this case a static analysis). After fetching, the alerts are combined using the respective ensembling technique. The evaluation metrics are then computed. Finally, the ensemble alerts and evaluation metrics are pushed to Loki and Prometheus, enabling the ensemble endpoint to handle asynchronously incoming results from different containers.
